HX901
Hydraulic offset hinge with 90 degree hold open function
Wall mounted
Suitable for 10 - 13.52mm thick glass
Maximum weight 65kg, maximum door width 900mm, maximum door height 2400mm
Maximum door openeing 95 degrees
2 hinges supplied, one with hydraulic control and one spring loaded
Ordering Information
Part code - GCHX901OS00
Description - Wall mounted hydraulic hinge set
Pack size - pair
Specification Information
Hydraulic hinge set for glass door which is wall mounted
Certification
12 month warranty
